200 × 250 mm print area
Full invitation suites, large logos and packaging panels in one impression.
Commercial, platen
KSF 3: Foil, emboss and deboss in one pull
Around a thousand KSF 3s have left the workshop, the commercial platen press that wedding stationers, printers and studios reach for when the work needs real pressure across a real print area.
- Print area200 × 250 mm
- Pressure3/4 ton
- Weight77 kg
At the bench
Built for the work, not the brochure
Three quarters of a ton of even platen pressure means the KSF 3 foils, embosses and debosses large dies in a single pull. It is the machine featured in Sal Studios’ “Foil, Pressure, Dwell, Heat” course, and the one we recommend when invitations, packaging and short-run print are the daily bread.
Perfect for
- Wedding stationery
- Foil + emboss work
- Short-run print
- Studio production
Why this machine
What makes the KSF 3 earn its keep
3/4-ton platen pressure
Even pressure edge to edge. Crisp foil and deep, sharp emboss.
Around 1,000 built
A commercial workhorse trusted by stationers and print studios across the world.
On camera
Watch the KSF 3 at work
The numbers
The KSF 3, by the numbers
Every machine is made to order in Essex. If a dimension doesn't quite fit your product, talk to us before you rule it out. Modifications are what we do.
- Print area
- 200 × 250 mm
- Table size
- 340 × 280 mm
- Type holder
- n/a
- Throat depth
- n/a
- Impression thickness
- 30 mm
- Pressure
- 3/4 ton
- Machine footprint
- 700 × 480 × 640 mm high
- Press weight
- 77 kg
Spare Parts · KSF 3
Every part, precisely placed.
Hover or tap a marker to see what it is. Add anything you need to your enquiry basket, then send it in one go. No account, no checkout.
KSF 316 parts
Hover a pin for its name · scroll or pinch to zoom · drag to pan
Parts list
- 01
Foil Discs
Set of 2
- 02
Foil Spring and Collars
1 spring and 2 collars for foil assembly
- 03
Foil guide arm
- 04
Rear Adjustment Knobs
Sold singularly, please specify top, middle or bottom as they do differ.
- 05
Chase Handle
Sold singularly
- 06
Rewind Belt
Complete belt with joiner
- 07
Rocker Switch
Please specify which version ( has been updated in later models)
- 08
Temperature Contoller
- 09
Table Gauge and thumb screws
- 10
Counter
- 11
Die Block
- 12
Chase and Die block
- 13
Spare Gloves
- 14
Replacement screwdriver
- 15
Foil take up Roller
- 16
Rubber Roller Springs
Keep looking
Explore more of the range
Parts online
Personalisation, portable
KSF 1
Over 500 sold. The portable personalisation press for notebooks, leather goods and gifting.
- Weight
- 19 kg
- Throat
- 140 mm
- Footprint
- 545 × 455 mm
Workshop, awkward shapes
KSF 2
Two set-up positions and a deep 260–460 mm throat for totes, wash bags and satchels that won’t sit flat.
- Weight
- 75 kg
- Throat
- 260–460 mm
- Impression
- 60 mm
Parts online
Studio, most adaptable
KSF 4
The KSF 1 and 2 combined: XYZ head movement and up to 200 mm impression clearance at just 24 kg.
- Weight
- 24 kg
- Impression
- Up to 200 mm
- Table
- 325 × 455 mm
Parts online
Personalisation, counter-top
KSF 1 Mini
The same great features, only smaller. Front-of-house personalisation for retail counters and pop-ups.
- Weight
- 14 kg
- Table
- 250 × 250 mm
- Footprint
- 400 × 255 mm
